CAMARA POC DAHUA HAC-HDW1200T DOMO 2MP 2.7-12MM

Camera

Image Sensor

2 MP CMOS

Max. Resolution

1920 (H) × 1080 (V)

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s?1/100000 s
NTSC: 1/30 s?1/100000 s

Min. Illumination

0.01 [email protected] (Color, 30 IRE)
0.001 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on)

S/N Ratio

>65 dB

Illumination Distance

60 m (196.85 ft)

Illuminator On/Off Control

Auto

Illuminator Number

2 (IR light)

Angle Adjustment

Pan: 0°?360°
Tilt: 0°?78°
Rotation: 0°?360°

Lens

Lens Type

Motorized Vari-focal

Auto Focus

No

Lens Mount

f14

Focal Length

2.7 mm?12 mm

Max. Aperture

F1.6

Field of View

H: 28.3°?98.2° V: 15.8°?51.9° D: 32.1°?116.7°

Iris Control

Fixed

Close Focus Distance

0.8 m (2.62 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.7 mm

47.4 m
(155.51 ft)

18.9 m
(62.01 ft)

9.5 m
(31.17 ft)

4.7 m
(15.42 ft)

12 mm

155.6 m
(510.50 ft)

62.2 m
(204.07 ft)

31.1 m
(102.03 ft)

15.6 m
(51.18 ft)

Video

Video Frame Rate

CVI:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
AHD:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
TVI:
PAL: 1080p@25 fps
NTSC: 1080p@30 fps
CVBS:
PAL: 960H
NTSC: 960H

Resolution

1080p (1920 × 1080) 960H (960 × 576/960 × 480)

Day/Night

Auto(ICR)/Color/B/W

BLC

BLC HLC DWDR

WDR

DWDR

White Balance

Auto Area white balance

Gain Control

Auto

Noise Reduction

3D NR

Illumination Mode

Smart IR

Mirror

Yes

Privacy Masking

Off/On (8 areas, rectangle)

Certification

Certifications

CE-LVD: EN 62368-1
CE-EMC: EN 55032 EN 55035
FCC: 47 CFR FCC Part 15, Subpart B
UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14

Port

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Power

Power Supply

12 VDC ± 30%

Power Consumption

Max 6.4 W (12 VDC, IR on)

Environment

Operating Temperature

?30 °C to +60 °C (?22 °F to +140 °F)

Operating Humidity

<95% (RH), non-condensing

Storage Temperature

?30 °C to +60 °C (?22 °F to +140 °F)

Storage Humidity

<95% (RH), non-condensing

Protection

IP67

Anti-corrosion Level

Basic Protection

Structure

Casing Material

Metal

Product Dimensions

f122 mm × 104.8 mm
(f4.80” × 4.13”)

Net Weight

0.58 kg (1.28 lb)

Gross Weight

0.74 kg (1.63 lb)

Installation

Wall mount ceiling mount vertical pole mount
